The helping hand of a hub drive unit and the off-road capability of a gravel bike means the eSILEX 600+ allows you to choose the trail you want to ride. Ride on or off-road with the combination of plump, gravel-ready tyres on agile 650b rims with drop barred efficiency and the subtle helping hand of the latest MAHLE ebikemotion X30 hub motor and 250 Wh battery. A smooth SRAM Apex single chainring wide-range groupset and hydraulic disc brakes mean effortless control while our carbon fork helps dampen vibrations, plus a full complement of mounts is ideal for backpacking trips.
If you are often looking for the off-road alternative when you are out on your bike or simply enjoy exploring the path unknown, then the eSILEX might be the perfect assisted bike for you. The latest rear-hub MAHLE X30 system with integrated battery offers a neutral support level whenever your journey requires some e-motor assistance. You can even use an externally mounted 208 Wh MAHLE Range Extender to boost range. Depending on where you want to take it, the eSILEX is available in the more rugged 650b or the more fast-rolling 700c set-up. Both versions come with gravel/off-road tyres for extra grip. A large number of fixing points on the frame as well as the fork, turn the eSILEX into an adventure rig without any fuss.
- Latest MAHLE ebikemotion X30 hub motor gives natural feeling assistance
- Triple butted aluminium frame with built-in 250 Wh battery
- Sleek 'normal bike' silhouette and low weight
- SRAM Apex drivetrain and hydraulic brakes
- Gravel tyres on more rugged 650b wheels
- Multiple frame and fork fixing points for extra carrying capacity
Awards & Media
- material: aluminium
- 700x45C / 700x42C (with fender) / 27,5x47C max. wheelsize
- 100x9/135x9mm axle standard
- BSA bottom bracket standard
- carbon
- max. 700x42C / 700x35C (with fender) / max. 50x650B wheelsize
- 160mm
- material: carbon
- 30.9mm diameter
- 0mm setback
- 28% recycled material
- V-mount
- incl. MERIDA minitool
- 40 teeth
- 170 mm-XS/S/SM/ML, 175 mm (L/XL)
- 10-50
- 12 speed
- 100x12mm width front hub
- 28 spoke holes
- Centerlock
- 19mm inner width
- 24mm height
- material: aluminium
- Tubeless ready (tubeless tape and valves not included)
- 650Bx47
- ShieldWall / TLR
- 650Bx47
- ShieldWall / TLR
- integrated
- weighed at frame size M
- Weight may vary depending on bike size, finish or possible specification changes due to supply chain issues.
| Frame Size | XS | S | M | L | XL |
| Tyre Sizes | 27.5" | 27.5" | 27.5" | 27.5" | 27.5" |
| ST seat tube [mm] | 470 | 490 | 510 | 530 | 560 |
| TT top tube [mm] | 525 | 540 | 555 | 570 | 585 |
| CS chain stay length [mm] | 431 | 431 | 431 | 431 | 431 |
| HTA head tube angle [°] | 69.5 | 70 | 70.5 | 71 | 71.5 |
| STA seat tube angle [°] | 75 | 75 | 75 | 75 | 75 |
| BD bottom bracket drop [mm] | 70 | 70 | 70 | 70 | 70 |
| HT head tube [mm] | 145 | 160 | 175 | 190 | 205 |
| FL fork length [mm] | 400 | 400 | 400 | 400 | 400 |
| R reach [mm] | 374 | 384 | 395 | 406 | 416 |
| S stack [mm] | 565 | 581 | 597 | 613 | 629 |
| WB wheel base [mm] | 1032 | 1044 | 1055 | 1066 | 1076 |
| SH stand over height [mm] | 748 | 767 | 785 | 804 | 830 |
